Abrites VN026 MQB Mileage Calibration and Key Learning Immo 5A/5B for VAG
| Abrites SKU | VN026 |
| Brand | Abrites |
| Product type | Software licence |
| Function | MQB cluster calibration; Immo 5A/5B data extraction for key programming |
| Vehicle makes | Volkswagen, Audi (MQB), Škoda, SEAT |
| Fits | Calibration: MQB 2012–2026, Immo 5A–5D. Key programming and module replacement: Immo 5A/5B, approx. 2012–2021 |
| Working method | RH850/V850 MCU read |
| Requires | AVDI interface with active annual subscription (AMS) |
| Additional hardware | ZN085 RH850/V850 programmer, ZN103 PROTAG |
| Availability | Delivered electronically |
Abrites / Software - Token
The Abrites VN026 licence provides instrument cluster calibration for the entire VAG MQB generation, covering supported VDO and JCI / Visteon dashboards from 2012 to 2026 across Immo 5A, 5B, 5C and 5D systems.
For MQB Immo 5A / 5B vehicles, VN026 also enables immobiliser data extraction from V850 and RH850 processors. The extracted data can be used for key programming, immobiliser-related module replacement and retrofit procedures.
Functionalities
- Calibration of supported MQB instrument clusters
- Coverage for Immo 5A, 5B, 5C and 5D dashboards
- Immobiliser data extraction for MQB Immo 5A / 5B
- Key programming support using the extracted immobiliser data
- Instrument cluster replacement
- Immobiliser-related ECU, TCU and ESL replacement support
- Instrument cluster retrofit support
Supported systems
- Immo 5A: VDO MQB analogue V850, VDO MQB Virtual Cockpit V850, JCI MQB analogue V850
- Immo 5B: VDO MQB analogue RH850, VDO MQB Virtual Cockpit RH850
- Immo 5C: VDO MQB analogue RH850 with CryptoCore, VDO MQB Virtual Cockpit RH850 with CryptoCore, JCI MQB Virtual Cockpit RH850 with CryptoCore
- Immo 5D: VDO non-immo MQB Virtual Cockpit with RH850 and CryptoCore
Immobiliser data extraction and key programming
By reading the V850 or RH850 MCU with the Abrites RH850/V850 programmer, the software automatically extracts and displays the key immobiliser information:
- Component Security (CS)
- Component Protection (CP — IKA and GFA)
- MAC
- Key data
- Power class
The extracted data can then be used for supported key programming procedures with Megamos AES keys.
Module replacement and retrofit
- Instrument cluster replacement
- Engine control unit (ECU) replacement
- Transmission control unit (TCU) replacement
- Electronic steering lock (ESL) replacement
- Instrument cluster retrofit
- Analogue instrument cluster to digital cockpit retrofit
Compatibility
- Calibration: MQB vehicles from 2012 to 2026 with compatible VDO or JCI / Visteon instrument clusters, Immo 5A, 5B, 5C and 5D — Volkswagen, Audi (MQB models), Škoda and SEAT
- Immobiliser data extraction, key programming and module replacement: MQB Immo 5A / 5B vehicles from approximately 2012 to 2021 with the immobiliser integrated into the instrument cluster, a V850 or RH850 MCU and Megamos AES keys
What you need alongside it. Abrites lists the ZN085 RH850/V850 programmer and the ZN103 PROTAG programmer as the hardware needed to complete all procedures. This licence is intended for lawful repair work — restoring the correct reading after a cluster has been repaired or replaced.
An AVDI interface with an active annual subscription is required to use this licence. Delivered electronically; your AVDI serial number is needed to process the order.
