Xhorse VVDI BMW BIMTool Pro Coding and Programming Tool

Features:

• Ethernet port for 10/100M programming via Ethernet.
• Wi-Fi 802.11b/g support with 150Mbps high-speed connection and OTA (Over-the-Air) upgrades.
• DoIP (Diagnostics over Internet Protocol) for vehicle/module programming.
• BMW ECU programming compatibility for NBT/CIC systems (requires network cable connection).
• Enhanced programming speeds for F/G Chassis models (requires network cable connection).
• Integration with BMW E-sys and Rheingold Diagnostic Systems, capable of replacing specialized tools (requires network cable connection).
• Direct ISN data reading capability for ECUs (N13/N20/N55/N63) without the need for disassembly.

Functions of VVDI BIM Tool:

• Automatically detect car chassis.
• Scan all car units.
• Calculate configuration for all units.
• Read/write car configuration (FA).
• Input HW/ZB numbers for programming.
• Calculate default coding from FA.
• Edit detailed coding information and modify car configuration.
• Support for DTC codes in multiple languages.

F-Series Programming, Coding, DTCs:

• Automatically detect car chassis.
• Read/write car configuration (FA).
• Calculate programming files from unit, car, or the entire database.
• Calculate default coding from FA.
• Edit detailed coding information and modify car configuration.
• Access a detailed list of special functions from coding.
• Support for DTC codes in multiple languages.

CAS1/CAS2/CAS3/CAS3+/CAS3++ ISTAP OBD Key Learning:

• Read and write key information.
• Perform key learning.
• Read/write EEPROM.
• Read ECU/gearbox synchronization codes.
• Write ECU/gearbox synchronization codes.
• Synchronize ECU and CAS.
• Synchronize CAS and ELV.
• Read ISN via OBDII.
• Reset KM via OBDII.
• Disable/enable keys.

CAS4(1L15Y)/CAS4+(5M48H) OBD Key Learning:

• Read CAS encryption key via OBDII.
• Perform key learning via programmer or ignition switch.
• Disable/enable keys.
• Erase key positions.
• Reset KM via OBDII.
• Read ISN via OBDII.
• Backup/restore coding.
• Update original CAS4 files.

FEM/BDC OBD Key Learning:

• Read FEM/BDC encryption key via OBDII.
• Perform key learning via programmer or ignition switch.
• Disable/enable keys.
• Erase key positions.
• Reset KM via OBDII.
• Read ISN via OBDII.
• Backup/restore coding.
• Exchange used FEM/BDC units.
• Close/open transport mode.
• Reset ECU lock.
• Switch on ignition without a working key.

CAS EEPROM Dump Key Learning:

• Support for EWS1, EWS2, EWS3, EWS4, CAS1(0K50E), CAS2(2K79X), CAS3(0L01Y), CAS3+(0L15Y), CAS3++ ISTAP(0L15Y, 0M23S).
• Prepare dealer keys via programmer.
• Disable/enable keys.
• Read ISN from working keys.

8HP Gearbox Renew:

• Clear ISN in 8HP gearbox.
• Backup/restore coding.
• Reset adaptation information.

Read Synchronization Code from E-Series ECU:

• Support for MEV9N46L, MSV70, MSS60, MS450, N62, etc.

Read E-Series/F-Series ECU ISN via OBDII:

• Support for MSV80, MSV801, MSD80, MSD81, MSD802, MSD812, MSD851.
• Support for MED17xx/MVD17xx/MEVD17xx/MV1722.
• Support for MED172/MEV17N46/ME17N45.
• Support for MEVD172Y/MEVD172/MEVD1725/B38/X63TU.
• Exchange ECU and CAS.
• Write ECU ISN via OBDII.
• Write ECU VIN via OBDII.
• Change ECU ISN and VIN using EEPROM dump.
• Change CAS1/CAS2/CAS3/CAS4 ISN and VIN using EEPROM dump.

CAS Repair (OBD & EEPROM):

• Repair ISTAP CAS.
• Repair CAS EEPROM (Service mode EEPROM) to start the engine after repair (CAS1, CAS2, CAS3, CAS3+, CAS3++ ISTAP).
• Restore ISN and VIN for CAS3+/CAS4+ lost dump files.
• Support for CAS3+(1L15Y) encrypted version.
• Support for CAS3++ (ISTAP) version.
• Support for CAS4+(5M48H) version.

File KM Calibration:

• Support for EWS1, EWS2, EWS3, EWS4.
• Support for CAS1(0K50E), CAS2(2K79X), CAS3(0L01Y), CAS3+(0L15Y, 0M23S).
• Support for CAS4(1L15Y), CAS4(5M48H, 1N35H).
• Support for E-Series dashboard EEPROM (M35080).
• Support for F-Series dashboard EEPROM (35160, 35128).

Unlock HITAG2 Key:

• Unlock HITAG2 keys made from BMW TOOL via programmer.

EWS3/EWS4 EEPROM Operations:

• Read and write EEPROM via CAS plug.
